Products / Calibration Services
Calibration Services
Nanmac proudly operates a globally recognized ISO/IEC 17025:2017 Accredited calibration laboratory, capable of testing thermocouples at temperatures up to 2,000°C—making it the highest temperature calibration lab in the world.
Our sensor calibrations are fully NIST traceable, and each comes with comprehensive documentation to confirm precise instrument calibration. As a brand-agnostic facility, Nanmac's lab is equipped to calibrate temperature sensors from any manufacturer, ensuring unparalleled accuracy and reliability across all equipment.
Key Features
ISO/IEC 17025:2017 Accredited
Testing Thermocouples at temperatures up to 2,000°C
Calibrations are NIST Traceable
Calibrate Temperature Sensors from any Manufacturer
Temperature Sensor Calibrations
Thermocouple Calibrations
- Types: J, K, T, S, N, E, R, B, C
- Range: 0°C – 2,000°C
- Form Factors: Bare Wire, Sheathed Probes, Unsheathed Probes
- Lengths: 8" minimum – 15' or longer
- Diameters: 3/8" maximum
RTD Calibrations
- Types: Pt100, Pt1000, Copper, Nickel
- Range: 0°C – 600°C
- Form Factors: Any
- Lengths: 8" minimum – 15' or longer
- Diameters: 3/8" maximum
Thermistor Probe Calibrations
- Contact Sales for details
Additional Instrument Testing
Pressure Testing
- Temperature Sensor Pressure Tests
- High-Pressure Seal Tests
- Up to 50,000 psia
Vacuum Leak Testing
- Sensors and Tubes using Helium
- Down to 20 mTorr
- Flows Down to 10-12 cc second
- “Helium Bomb” Tests Upon Request
Insulation Resistance Testing
- Test Temperature Sensor Insulation to 260 GΩ @ 1,000 V
Loop Resistance Testing
- with high precision multimeters, we can test the resistance of a thermocouple with a range from 0.00001 Ω - 1.00 GΩ
Request a Quote
Please contact us to request a quote.
